XGW-12 Outdoor Cable-Distribution Ring Main Unit

The XGW-12 outdoor ring main unit provides cable switching and distribution in a pad-mounted enclosure for 12 kV networks. A sealed SF6-insulated tank houses the switching components, allowing the unit to be installed at outdoor cable-ring or terminal distribution points close to the feeder route.

Rated at 630 A, the series can be configured around the required number of ways, incoming cable direction and automation provisions. The outdoor enclosure limits environmental exposure to the switching equipment, with the final circuit arrangement and protection functions matched to the network scheme.

Technical Specifications

Rated Voltage	12 kV
Rated Current	630 A
Short-Circuit Rating	25 kA
Insulation Medium	SF6 gas
Gas Tank IP Rating	IP67
Installation	Outdoor, pad-mounted

Key Features

Weatherproof outdoor enclosure
Sealed SF6 insulation
Pad-mounted cable distribution
Sealed construction helps reduce routine maintenance; inspection follows the equipment manual and site conditions.

Typical Applications

Residential districts and city streets
Industrial parks
Airports and commercial centres

Installation & Aftercare

Prepare the site, plan routine checks and keep service records.

What needs to be ready before installation?

Use the designed plinth and cable approach, with drainage that prevents standing water at doors and cable entries.
Keep operating doors accessible and allow the specified cable bend, termination and pressure-relief space.
IP67 applies to the gas tank; specify weather protection separately for the outer enclosure, cable areas and auxiliary equipment.

What should operators check during routine rounds?

Inspect locks, seals, corrosion and drainage, especially after severe weather; check position indications and any fitted gas-pressure alarm.

What is covered during planned maintenance?

During planned isolation, qualified personnel inspect cable terminations, earthing and external operating mechanisms.
Water entry, damaged seals or abnormal gas indication requires attention; sealed-tank work belongs to authorised service personnel.

Customization Options

Define the electrical configuration and the details needed for your site.

Network arrangement: Incoming ring circuits, transformer feeders, terminal supplies and future extension requirements.
Switching units: Choose from this model’s listed load-switch, switch-fuse and breaker units; match protection to the transformer or feeder.
Protection & metering: Fuse or relay protection arrangement, CT ratios, metering and fault-indication requirements.
Cable interfaces: Cable count, cross-section, termination type and earthing connections.
Controls & enclosure: Operating mechanism, auxiliary supply and remote signalling; enclosure and site conditions for engineering review.

Project-specific options and accessories are confirmed in the quotation and approved drawings.
